参数
|
Specifications
|
技术指标/Technique
|
|
额定容量
|
Capacity
|
1, 2, 5, 10, 60t
|
|
输出灵敏度
|
Rated output
|
2.0±0.006mV/V
|
|
零点输出
|
Zero balance
|
±1% F.S.
|
|
非线性
|
Non-linearity
|
0.25%F.S.
|
|
滞后
|
Hysteresis
|
0.05%F.S.
|
|
重复性
|
Repeatability
|
0.05%F.S.
|
|
蠕变（30min）
|
Creep(30min)
|
0.05%F.S.
|
|
温度灵敏度漂移
|
Temp.effect on output
|
0.05%F.S./10℃
|
|
零点温度漂移
|
Temp.effect on zero
|
0.05%F.S./10℃
|
|
输入电阻
|
Input impedance
|
400±10Ω
|
|
输出电阻
|
Output impedance
|
352±2Ω
|
|
绝缘电阻
|
Insulation
|
≥5000MΩ/100VDC
|
|
激励电压
|
Recommended excitation
|
5V
|
|
最大激励电压
|
Maximum excitation
|
15V
|
|
温度补偿范围
|
Compensated temp range
|
-10~40℃
|
|
工作温度范围
|
Operation temp range
|
-30~70℃
|
|
安全超载
|
Safe overload
|
150%F.S.
|
|
极限超载
|
Ultimate overload
|
200%F.S.
|
|
电缆线尺寸
|
Cable size
|
Φ6×12000mm
|
|
单件重量
|
Weight approx.
|
1-5kg
|
|
材料
|
Material
|
Alloy Steel（合金钢）
|
|
防护等级
|
IP Class
|
IP68
|
